Glass Fiber Capsule Filters
The PoreCap® series of Glassfiber capsule filters are ideal for prefiltration and protection of downstream sterilizing grade filters and are especially designed for high particle retention, dirt holding and pre-filtration applications.
These are available in multiple pore size options ranging from 0.5µm to 2µm with 1-10 inch sizes. Each Glassfiber capsule filter is validated for flow rate, heat stability and integrity.
Membrane Characteristics: Our Glassfiber Capsule filters incorporate a polypropylene prefiltration layer and an upstream high dirt capacity glass fibre media layer suitable for removal of unwanted particulates.
Materials of Construction
| Membrane: | Microglassfiber |
| Housing: | Polypropylene |
| Core: | Polypropylene |
| End Connections: | Polypropylene |
| Rings: | Silicone (Only with 1/4" MNPT) |
Operational Parameters
| Max Temp: | 80 °C @ ≤ 2 Kg/cm² |
| Max Pressure: | 3.5 Kg/cm² @ 25 °C for forward, 0.7 Kg/cm² @ 25 °C for reverse |
Sterilization
| ETO: | Yes |
| GAMMA : | Yes |
| Non-sterile: | Yes |
| Non-sterile (Gamma strerilizable): | Yes |
Drug Specific Filter Validation Services
Through, nSure Validation Services, we offer a complete range of filter validation services to qualify your molecules with our Filters in accordance with the requirements listed in PDA TR#26 and in compliance with international regulatory bodies such as USFDA and EU GMP.
