Nylon Capsule Filters
The PoreCap® series of Nylon Capsule Filters are available in 0.22µm, 0.45µm, and 0.8µm with 0.22µm/0.45µm/0.8µm upstream combination and are specially designed and developed for high purity and final filtration application i.e. water, solvents, sterile filtration, organic and aqueous samples filtration.
These filters are available in 1, 2, 5, 8 and 10 inches nominal size scale for laboratory to full scale production.
They offer versatile performance in terms of fast flow with excellent throughput. Each capsule filter is validated for retention efficiency, integrity test, flow rate, heat Stability, fibre particle release, extractable and biosafety.
Membrane Characteristics: Assembled with our naturally hydrophilic Nylon 66 membranes, these Nylon Capsule Filters provides excellent chemical compatibility and offer higher throughputs
APPLICATIONS
- Quality Buffers preparation
- Filtration of Water for Injection (WFI)
- Solvent Filtration
- Sterile Filtration of hormonal injectables
- Filtration of LPVs & SVPs
- Final sterile grade filtration
- Filtration of Non-protein solutions, Aqueous and organics chemicals
Microbial Validation
Validated as per the ASTM F 838-05 requirements for determining bacterial retention of membrane filters used for liquid filtration
FDA Compliant
Biosafety & Extractables
Integrity Tested
Global Manufacturing Standards
Easy Identification & Tracking
Each filter unit has a unique identification marking which enables quick backtracking
100% Integrity Tested
Guaranteed Specification as per Actual Data
Non Leachable
Ergonomically Designed & Developed
TECHNICAL SPECIFICATIONS
Nylon Capsule Filters
| Materials of Construction | ||
| Membrane: | Nylon-6,6 | |
| Housing: | Polypropylene | |
| Core: | Polypropylene | |
| End Connections: | Polypropylene | |
| Rings: | Silicone (Only with 1/4" MNPT) | |
| Operational Parameters | ||
| Max Temp | 80 °C @ ≤ 2 Kg/cm2 | |
| Max Pressure | 4.1kg/cm2 @ 30 °C | |
| Autoclavable | 30 autoclave cycles of 30 minutes at 121 °C | |
| Bubble Point: | ||
| 0.22µm: | ≥ 3447 mbar (50 psi) (with water wetted) | |
| 0.45µm: | ≥ 2206 mbar (32 psi) (with water wetted) | |
| 0.80µm: | ≥ 965 mbar (14 psi) (with water wetted) | |
| Max Air Diffusion Flow (for 8" & 10″ Capsule): | ||
| 0.22µm: | ≤ 30 mL/min @ 2551 mbar (37 psi) | |
| 0.45µm: | ≤ 35 mL/min @ 1655 mbar (24 psi) | |
| 0.80µm: | ≤ 30 mL/min @ 689 mbar (10 psi) | |
| Microbial Retention: | ||
| 0.22µm: | LRV > 7 for Brevundimonas Diminuta | |
| 0.45µm: | LRV > 7 for Serratia marcescens | |
| 0.80µm: | LRV > 4 for Staphylococcus Aureus |
| Effective Filtration Area: | |||||
| Length: | 1″ | 2″ | 5″ | 8″ | 10″ |
| Area: | 0.025m2 | 0.05m2 | 0.10m2 | 0.20m2 | 0.60m2 |
QUALITY ASSURANCE & VALIDATION
All filters are 100% integrity tested and are developed and manufactured under an ISO 9001:2015 certified Quality Management System and designed to be used in cGMP compliant processes.
Microbial Validation
All our Cartridge and Capsule filters are validated as per the ASTM F 838 requirements for determining bacterial retention of sterilizing grade filters
Certificate of Quality
All our products are delivered along with a Certificate of Quality (CoQ) mentioning the materials of construction and testing & quality parameters
Throughput Studies
We help you select the perfect mix of prefilters and final filters by performing small scale filtration and determining the filtration area to reach your desired throughput
Extractables & Leachables
Our Extractables & Leachables testing study is a highly effective way to quantify and assess risks associated with leachable impurities from filters
