Positively Charged Nylon Capsule Filters
Nupore PoreCap® positively charged Nylon capsule filters are absolute retention filters for endotoxin removal and sterilization of liquids.
Positively Charged Nylon Capsule filters are manufactured with a single layer of nylon-66 membrane and available in 0.22µm, 0.45µm and 0.80µm ratings across different sizes ranging from 1" to 10".
These are hydrophilic, autoclavable, heat resistant, non-media migrating and biologically inert filters with wide chemical compatibility, ideal for filtration and sterilization of buffers, organic solvents and injectables.
Membrane Characteristics: These capsule filters incorporate the positively charged Nylon-66 membrane which has a cationic functional group added to the membrane which provides an extra functionality of retaining smaller negatively charged particles such as endotoxins.
APPLICATIONS
- Endotoxin Removal
- Filtration of buffers and other non-aqueous solutions
- Filtration of Aqueous and organic solvents
- Sterilization of hormonal injectables
Microbial Validation
Validated as per the ASTM F 838-05 requirements for determining bacterial retention of membrane filters used for liquid filtration
FDA Compliant
Biosafety & Extractables
Integrity Tested
Global Manufacturing Standards
Easy Identification & Tracking
Each filter unit has a unique identification marking which enables quick backtracking
100% Integrity Tested
Guaranteed Specification as per Actual Data
Non Leachable
Ergonomically Designed & Developed
TECHNICAL SPECIFICATIONS
Positively Charged Nylon Capsule Filters
| Materials of Construction | ||
| Membrane: | Nylon-6,6 (+ve Charged) | |
| Housing: | Polypropylene | |
| Core: | Polypropylene | |
| End Connections: | Polypropylene | |
| Rings: | Silicone (Only with 1/4" MNPT) | |
| Operational Parameters | ||
| Max Temp | 80 °C @ ≤ 2 Kg/cm2 | |
| Max Pressure | 3.5kg/cm2 @ 25 °C | |
| Autoclavable | 1 autoclavable cycles of 30 minutes at 121 °C | |
| Bubble Point: | ||
| 0.22µm: | ≥ 3450 mbar (50 psi) (with water wetted) | |
| 0.45µm: | ≥ 2268 mbar (30 psi) (with water wetted) | |
| Max Air Diffusion Flow (for 8" & 10″ Capsule): | ||
| 0.22µm: | ≤ 30 mL/min @ 2882 mbar (36 psi) | |
| 0.45µm: | ≤ 35 mL/min @ 1650 mbar (24 psi) | |
| Microbial Retention: | ||
| 0.22µm: | LRV > 7 for Brevundimonas Diminuta | |
| 0.45µm: | LRV > 7 for Serratia marcescens |
| Effective Filtration Area: | |||||
| Length: | 1″ | 2″ | 5″ | 8″ | 10″ |
| Area: | 0.025m2 | 0.05m2 | 0.10m2 | 0.20m2 | 0.60m2 |
QUALITY ASSURANCE & VALIDATION
All filters are 100% integrity tested and are developed and manufactured under an ISO 9001:2015 certified Quality Management System and designed to be used in cGMP compliant processes.
Microbial Validation
All our Cartridge and Capsule filters are validated as per the ASTM F 838 requirements for determining bacterial retention of sterilizing grade filters
Certificate of Quality
All our products are delivered along with a Certificate of Quality (CoQ) mentioning the materials of construction and testing & quality parameters
Throughput Studies
We help you select the perfect mix of prefilters and final filters by performing small scale filtration and determining the filtration area to reach your desired throughput
Extractables & Leachables
Our Extractables & Leachables testing study is a highly effective way to quantify and assess risks associated with leachable impurities from filters
Why Choose Us
With our extensive knowledge in membrane filtration and a wide range of products available at every stage of the process, along with our exceptional customer service, we are able to establish ourselves as the preferred partner.
Extensive Product Portfolio
At Nupore, we offer a wide range of filtration for your process requirements. Use our quick guide to land instantly at the product of your choice
Proven Membrane Technology
Fast Shipping
Talk To Us
Need assistance choosing the right product for your application, or have a question about ordering from us? Connect with an Expert
